Corsair PSU VS Series VS550 — 550 Watt 80 PLUS White Certified Power Supply PSU

Corsair PSU VS Series VS550 — 550 Watt 80 PLUS White Certified Power Supply PSU

BND85.00

Ask about this product

The CORSAIR VS Series combines stable 80 PLUS efficiency power and affordable pricing from the world’s most trusted name in PC power supplies.

Model

Brand: CORSAIR

Series: VS Series VS550

Model: CP-9020171-NA

Details

Type: ATX12V v2.31 / EPS 2.92

Maximum Power: 550W

Fans: 1 x 120mm Thermally Controlled Sleeve Bearing Fan

PFC: Active

Main Connector: 24Pin

+12V Rails: Single

PCI-Express Connector: 2 x 6+2-Pin

SATA Power Connector: 6

Energy-Efficient: 80 PLUS White Certified

Over Voltage Protection: Yes

Input Voltage: 100 - 240 V

Input Frequency Range: 47 - 63 Hz

Input Current: 10 - 5 A

Output: +3.3V@24A, +5V@20A, +12V@44A, -12V@0.3A, +5VSB@3A

MTBF: 100,000 hours

Approvals: FCC, cTUVus, TUV, CCC, BSMI, CE, CB, TUV-S, EAC, RCM, KC, Reach, WEEE and RoHS

Dimensions: 5.91" x 4.92" x 3.39"

Max PSU Length: 125 mm

Weight: 4.12 lbs.

Features

Connectors: 1 x 24-pin ATX
1 x EPS12V/ATX12V
2 x PCIe
6 x SATA
2 x SATA-PATA-PATA-FDD

Features: 80 PLUS efficiency: Runs cooler and uses less power than non-certified power supplies

3-year warranty: Backed by CORSAIR’s legendary technical support and customer service

Black housing, cable sleeves and connectors: Give your build the high-end look without breaking the bank

Thermally controlled 120mm fan: Quiet operation across a wide range of loads
